Plug and socket assemblies in SolidWorks

The brief

Design a metal socket, casing and plug assembly in SolidWorks, in 2 mm and 4 mm versions, with formal technical drawings.

What I did

I modelled the parts and assemblies for both sizes and produced drawings to standard, revising the parts and drawings several times before the final submission.

Result

Complete part, assembly and drawing sets for both versions.
